Raceways
The product comes in a strong structure that is safe for the employees also to use. Secondly, raceways are easy to install as it hardly takes a few minutes to install them perfectly, also the design makes it super convenient to route the cable whenever needed. Since raceways are made with premium quality materials, they are strong and easy to maintain.
Product Images
Raceways
The raceway is a prominent category of cable trays that is used mainly for routing cables. This category of cable tray is ideal for managing cables or wires of multiple categories of machinery as well as communication rooms. Raceways give full protection from the dirt, debris, or any additional particle that could harm the wires. Raceways add grace to the overall look of the interiors. As per the look of the interiors, the colour and design of the raceway can be changed. There is a current usage of electric raceways that are safe to be used in the industries.
Key Features
- Anti-corrosive
- Ideal for handling extreme pressures and weight
- Made with high-quality materials for enhanced durability
- Easy to maintain and install
Technical Specifications
Material: Galvanized steel, Stainless steel, PVC
Widths: 50mm to 300mm
Heights: 25mm to 100mm
Lengths: 2m, 3m (custom lengths available)
Cover Options: Hinged, removable, fixed
Ingress Protection: Up to IP65
Finish Options: Galvanized, Powder coated, Stainless steel
Compliance: IEC 61537, IS 2309
Technical Specifications
Material Finish Options
| S.No | Material Finished | Specifications | Recommended |
|---|---|---|---|
| 1 | Pre-Galvanized | As Per Specifications | Indoor |
| 2 | Hot - Dip Galvanized | As Per IS 4759,2629, 2633 | Indoor & Outdoor |
| 3 | Powder Coated | As Per Specifications | Indoor |
| 4 | Stainless Steel | As Per Specifications 304, 316. | Indoor & Outdoor |
| 5 | Aluminum | As Per Specifications | Indoor |
Note:
- • R means regular sizes which used in the market
- • NR means not regular size production is done as per customer requirement
- • NA it means Not Available or likely to be used in the market but as per customer requirement, we supply.
Additional Specifications
Note: Available Thickness 1.6 mm, 2 mm, 2.5 mm, 3 mm
Length Available: 2500 mm to 3000 mm
